Imaging Source DMK 23F274 Monochrome Camera W/ Cable

Imaging Source DMK 23F274 Monochrome Camera W/ Cable

Regular price $264.99 USD
Regular price Sale price $264.99 USD
Sale Sold out
Shipping calculated at checkout.

2 in stock


Camera was pulled from a working environment.

Unit was lightly used showing no major signs of wear.

Additional information below, information was found online and is for reference only.

On hand and ready to ship!

Thank you for checking out our listing.


Manufacturer The Imaging Source
Model Number DMK 23F274
SKU 19-27788
Ref 23-35497
More Info
More Info

General behavior

Sensitivity 0.05 lx

Dynamic range 8/12 bit

Video formats @ frame rate (maximum) 1,600×1,200 (1.9 MP) Y800 @ 20 fps

1,600×1,200 (1.9 MP) Y16 @ 15 fps

Interface (optical)

IR cut filter

Sensor type CCD

Sensor specification Sony ICX274AL

Shutter global

Format 1/1.8 inch

Pixel size H: 4.4 µm, V: 4.4 µm

Lens mount C/CS

Interface (electrical)

Interface FireWire 800

Supply voltage 11 VDC to 13 VDC

Current consumption approx 400 mA @ 12 VDC

Auto iris control


I/Os Interface (mechanical)

Dimensions H: 29 mm, W: 29 mm, L: 47 mm

Mass 65 g


Shutter 1/100,000 s to 30 s

Gain 0 dB to 36 dB


Temperature (operating) -5 °C to 45 °C

Temperature (storage) -20 °C to 60 °C

Humidity (operating) 20 % to 80 % (non-condensing)

Humidity (storage) 20 % to 95 % (non-condensing)
